Bare metal, shells and clouds ​- IT2Research​

18.03.2024 - M. Blaschek - PhD Seminar @ IMGW

What can you expect from this presentation?

- Asking Questions (anytime, please interrupt) - This presentation is for you!

  • Hardware

  • Data and Storage

  • Services

    • Teachinghub via Moodle

  • Rules

  • Updates

    - VSCode

Bare metal @ Department

.left-column[

AURORA

.right[] Arsenal, Development & Visual (VNC) Node - Storage (800 TB) - Storage (11 TB SSD)

JET

.right[
] Arsenal, Computing Cluster - 2x Login (JET01 (vnc),JET02 (hub)) - 17x Compute - Storage (3.7 PB) - SLURM - JET2VSC connection ]

.right-column[

SRVX1

.right[] Arsenal, Teaching Node

VSC

.right[

]
Arsenal, HPC Cluster - VSC4 5x Nodes - VSC5 11 Nodes - VSC5 1x GPU - Shared HOME (200GB) - Shared DATA (100TB) - # of files!!! - SLURM - Project resources ]

Important Things @UNIVIE

The ZID offers a lot of information on its services, most importantly your u:account.

Services:

  • u:account everything depends on it
  • vpn access to only university wide things (our servers)
  • u:cloud University cloud
  • u:access library access for publications
  • gitlab/mattermost code development / socializing
  • u:wiki documentation of workflows, group communication, tutorials, intranet, ...
    • Lots of tutorials for specific problems (travel, expenses, new employees, printer, ...)
    • HPC / Computing information and guidelines
    • Please login once. More access can be granted afterwards.
  • wolke.img.univie.ac.at
    • Landing Page of IT service @ IMGW
    • User Management IPA

class: center, middle

How to connect? - HOME / UNI

Tools - How to connect?

Depending on your operating system (OS) you should find the right tool to connect.

Options:

  • Web browser - Jupyterhub running Jupyter Notebooks
  • SSH (Windows: Putty, ...)
  • SFTP (Windows: Mobaxterm, winscp, ...)
  • VNC to JET01 or AURORA
    • install a vnc client on your OS
    • launch a vnc server, run: userservices vnc
    • connect to VNC via a vnc viewer (tigervnc) server:port
    • more information on @gitlab @VNC

Login and Passwords

When you login the first time, you will need to change your password. Please be advised that you should choose a secure one. A password manager is recommended.

Bash
1
2
3
4
5
$ ssh [user]@login.img.univie.ac.at
$ ssh [user]@jet01.img.univie.ac.at
$ ssh [user]@jet02.img.univie.ac.at
# from home to jet directly
$ ssh -J [user]@login.img.univie.ac.at [user]@jet01.img.univie.ac.at

Each of these require a different password:

  • IMGW Servers
  • u:account
  • eduroam (WLAN)
  • VSC
  • Gitlab / Mattermost

Services @ Servers

All servers try to be up to date and will be updated regularly, the base OS is Red Hat OS 8/AlmaLinux 8.

All servers handle software like this: - environment modules, run: modules av * different compilers: gnu, intel * libraries: math, eccodes, netcdf ,... * different MPI * tools: teleport, ecaccess, ... - userservices, run: userservices * quota * server-schedule * weather * containers * yopass * filetransfer * transfersh - singularity containers, advanced topic. * building singularity containers for HPC applications

Services @ Servers 2

Locations on Servers are very important. Where to store and find what?

name Server Path Quota comment
HOME aurora /srvfs/home/[user] 100 GB source code, daily backup
HOME jet01 /jetfs/home/[user] 100 GB source code, daily backup
--- --- --- --- ---
SCRATCH aurora /srvfs/scratch/[user] 1 TB data, no backup
SCRATCH aurora /srvfs/tmp/[user] 1 TB data, no backup
SCRATCH jet01 /jetfs/scratch/[user] no data, no backup
--- --- --- --- ---
DATA aurora /srvfs/data/[dataset] no data, daily backup, constant
SHARED-DATA aurora /srvfs/shared/[dataset] no data, no backup, shared
SHARED-DATA jet01 /jetfs/shared-data/[dataset] no data, no backup, shared

All these paths can be remembered by running userpaths

DATA Management

Science is about computing, but mostly about data and storing that data.

name Server Path
DATA aurora /srvfs/data/[dataset]
SHARED-DATA aurora /srvfs/shared/[dataset]
SHARED-DATA jet01 /jetfs/shared-data/[dataset]

Please fill in the Database and follow the Data Guidelines, that can be found in these directories.

Add a short decsription of your data and whom to contact for more information.

Support & Contacts

In case you need help, whom to contact?

  • Servers > M. Blaschek
  • VSC > M. Blaschek
  • Gitlab > M. Blaschek
  • Everything else > M. Ristic

Use Mattermost or send mail to IT or Gitlab Issues

class: center, title

Questions
